Case file / Education
Shafter Unified canopies
Solar canopies across three campus lots, built in two summer windows. The structures carry the array, the lot lighting and the conduit for a future electric bus fleet.
- Array
- 614 kW DC
- Inverters
- 500 kW AC
- Annual output
- 1,038 MWh
- Permission to operate
- November 2024
Specification
The numbers on the record
| Client | Shafter Unified School District |
|---|---|
| Location | Shafter, CA |
| Array rating | 614 kW DC |
| Inverter rating | 500 kW AC (DC to AC ratio 1.23) |
| Modules | 1,116 at 550 W |
| Structure | Single-slope steel canopies over three parking lots |
| Storage | None; EV conduit stubbed for 12 future ports |
| Modelled annual production | 1,038,000 kWh |
| Specific yield | 1,691 kWh per kW DC per year |
| Load offset | 58 percent |
| Construction window | 14 weeks |
| Permission to operate | November 2024 |
What made it hard
The constraints
- All heavy construction confined to the June to August break, across two consecutive summers.
- A plan-review cycle for structures on a school site that had to be started before the design was fully priced.
- Preserving every existing accessible stall while keeping column spacing economical.
What we did about it
The approach
- Single-slope canopies at 7 degrees, oriented to the existing drive aisles so no stall was lost and no aisle narrowed.
- Column grid set on the stall stripe lines, with longer spans used only over the accessible parking bay.
- Under-canopy LED lighting on photocell control, replacing four ageing pole fixtures and removing their maintenance line.
- Switchgear and conduit sized for twelve future DC charging ports, with pull boxes left at the bus loading zone.
Result
Outcome
- System size
- 614 kW DC / 500 kW AC
- Modelled annual output
- 1,038,000 kWh
- District load offset
- 58 percent
- Covered parking
- 186 stalls across three lots
- Future EV capacity stubbed
- 12 ports
Shafter Unified canopies, Shafter, CAParents noticed the shade before anyone noticed the savings. Both showed up, but the shade showed up first.
